NL | TROX Denmark A/S

NL

Med lyddæmpende funktion

Lyddæmpende jalousirist til beskyttelse af ventilationsanlæg mod vind og indtrængende regn samt løv og fugle

Maksimal bredde 1800 mm, maksimal højde 2250 mm
Strømningsgunstigt formede lameller giver lavt tryktab
Lav strømningsstøj
Alle ventilationsdata er målt i strømningstekniske og akustiske laboratorier
Absorptionsmateriale beskyttet af glasvæv og perforeret plade
Dobbeltgitter til høje akustiske krav
Ikke aktiv rist, uden akustisk funktion, til optisk tilpasning
Delte udførelser, til store dimensioner

Valgfrit udstyr og tilbehør

Pulverlakeret eller eloxeret

Anvendelse

Anvendelse

Lyddæmpende jalousirist fra serien NL til indblæsnings- og facadeåbninger i ventilationsanlæg
Beskytter mod indtrængen af regn, løv og fugle
Anbefalet tilstrømningshastighed for indblæsningsåbninger maks. 2 – 2,5 m/s
Beskyttelse mod vejr og støj ved lav byggedybde

Særlige egenskaber

To konstruktionsdybder til normale og til høje akustiske krav
Aerodynamisk formede lameller
Absorptionsmaterialet beskyttet af perforeret plade

Beskrivelse

Varianter

NL: lyddæmpende jalousirist
NL-H: dobbeltrist til høje akustiske krav
NL-D: ikke aktiv rist til optiske tilpasninger

Udførelser

S: galvaniseret stål
A: aluminium

Downloads

Produktoplysninger

Websideprint NL
Product data sheet Type NL

Product data sheet 1,5 MB pdf
Type NL

6/6/DA/2 220 KB pdf

Certifikater

Declaration of hygiene conformity Type NL

NL_HC_2020_06_05_DE_en Hygiene certificate 1,8 MB pdf
